Square Rotary Broach Tools

Our Square Rotary Broach (or Wobble Broach) tools are made from M-2 High Speed Steel
and include a pressure relief vent hole.
We offer PM M-4, M-42 and PM T-15 H.S.S. - TiN, TiAN & TiCN Coatings are available.

Hex Rotary Broach 8mm Diameter Shank
Internal Square Rotary Broaches
1.25" Overall Length

Nominal Broach Size {Inches}	Across Flats	Broach Depth	Price	Order Online
1/16" Square Broach	.0635	.127	$48.00	Order
5/64" Square Broach	.0790	.158	$48.00	Order
3/32" Square Broach	.0950	.190	$48.00	Order
7/64" Square Broach	.1110	.222	$48.00	Order
1/8" Square Broach	.1265	.253	$48.00	Order
9/64" Square Broach	.1425	.285	$48.00	Order
5/32" Square Broach	.1585	.317	$48.00	Order
11/64" Square Broach	.1740	.348	$48.00	Order
3/16" Square Broach	.1895	.379	$48.00	Order
7/32" Square Broach	.2215	.443	$48.00	Order
1/4" Square Broach	.2525	.505	$65.00	Order
9/32" Square Broach	.2840	.568	$65.00	Order
5/16" Square Broach	.3155	.631	$65.00	Order
11/32" Square Broach	.3470	.650	$74.00	Order
3/8" Square Broach	.3785	.650	$74.00	Order
13/32" Square Broach	.4100	.650	$74.00	Order

Nominal Broach Size {Metric}	Across Flats	Broach Depth	Price	Order Online
1.30mm Square Broach	.0515	.103	$48.00	Order
1.50mm Square Broach	.0610	.122	$48.00	Order
2.00mm Square Broach	.0810	.162	$48.00	Order
2.50mm Square Broach	.1010	.202	$48.00	Order
3.00mm Square Broach	.1210	.242	$48.00	Order
3.50mm Square Broach	.1410	.282	$48.00	Order
4.00mm Square Broach	.1610	.322	$48.00	Order
5.00mm Square Broach	.2000	.400	$48.00	Order
6.00mm Square Broach	.2400	.480	$65.00	Order
7.00mm Square Broach	.2790	.558	$65.00	Order
8.00mm Square Broach	.3185	.637	$65.00	Order
9.00mm Square Broach	.3580	.650	$74.00	Order
10.00mm Square Broach	.3985	.650	$74.00	Order
11.00mm Square Broach	.4370	.650	$74.00	Order
12.00mm Square Broach	.4775	.650	$74.00	Order

Hex Rotary Broach .500" Diameter Shank
Internal Square Rotary Broaches
1.75" Overall Length

Nominal Broach Size {Inches}	Across Flats	Broach Depth	Price	Order Online
3/32" Square Broach	.0950	.190	$54.00	Order
7/64" Square Broach	.1110	.222	$54.00	Order
1/8" Square Broach	.1265	.253	$54.00	Order
9/64" Square Broach	.1425	.285	$54.00	Order
5/32" Square Broach	.1585	.317	$54.00	Order
11/64" Square Broach	.1740	.348	$54.00	Order
3/16" Square Broach	.1895	.379	$54.00	Order
7/32" Square Broach	.2215	.443	$54.00	Order
1/4" Square Broach	.2525	.505	$54.00	Order
9/32" Square Broach	.2840	.568	$54.00	Order
5/16" Square Broach	.3155	.631	$54.00	Order
11/32" Square Broach	.3470	.694	$54.00	Order
3/8" Square Broach	.3785	.757	$69.00	Order
13/32" Square Broach	.4100	.820	$69.00	Order
7/16" Square Broach	.4415	.883	$69.00	Order
15/32" Square Broach	.4730	.946	$69.00	Order
1/2" Square Broach	.5045	1.010	$69.00	Order
17/32" Square Broach	.5360	1.010	$69.00	Order
9/16" Square Broach	.5675	1.010	$94.00	Order
5/8" Square Broach	.6305	1.010	$94.00	Order
11/16" Square Broach	.6935	1.010	$94.00	Order
23/32" Square Broach	.7250	1.010	$94.00	Call
3/4" Square Broach	.7565	1.010	$94.00	Call

Nominal Broach Size {Metric}	Across Flats	Broach Depth	Price	Order Online
2.00mm Square Broach	.0810	.162	$54.00	Order
2.50mm Square Broach	.1010	.202	$54.00	Order
3.00mm Square Broach	.1210	.242	$54.00	Order
3.50mm Square Broach	.1410	.282	$54.00	Order
4.00mm Square Broach	.1610	.322	$54.00	Order
5.00mm Square Broach	.2000	.400	$54.00	Order
6.00mm Square Broach	.2400	.480	$54.00	Order
7.00mm Square Broach	.2790	.558	$54.00	Order
8.00mm Square Broach	.3185	.637	$54.00	Order
9.00mm Square Broach	.3580	.716	$69.00	Order
10.00mm Square Broach	.3985	.797	$69.00	Order
11.00mm Square Broach	.4370	.874	$69.00	Order
12.00mm Square Broach	.4775	.955	$69.00	Order
13.00mm Square Broach	.5170	1.010	$69.00	Order
14.00mm Square Broach	.5565	1.010	$94.00	Order
15.00mm Square Broach	.5965	1.010	$94.00	Order
16.00mm Square Broach	.6355	1.010	$94.00	Order
17.00mm Square Broach	.6750	1.010	$94.00	Order
18.00mm Square Broach	.7150	1.010	$94.00	Order
19.00mm Square Broach	.7545	1.010	$94.00	Order

Our Square Broach tools are similiar to Square Punch tools.
The four sided polygon cutter is designed to cut right to size
when using the Polygon Tool Holder.
Custom or special order sizes are available by calling (239) 628-4800.
